Country of Origin: China
Warranty: 3 years manufacturer's warranty for this biosafety cabinet excluding consumables, such as UV lamp, LED lamp and filters. If warranty is expired, the manufacturer will charge for replacement parts.
Estimated lead time: Made upon order. Ships in 8 weeks from order and payment.
1. Large LCD display, all information displayed.
2. Motorized front window.
3. Automatic air speed adjustable with filter block.
4. Side & back wall composition is single piece of stainless steel with 45° corner
5. Ergonomic front 10° slanted to offer operator comfort while working for long time, reduce glare and maximize reach into the work area.
6.Interlock function: UV lamp and front window; UV lamp and blower, fluorescent lamp; Blower and front window.
|External Siz (W*D*H)||1383×775×2295mm (54.44"x 30.51" x 90.35")|
|Internal Size (W*D*H)||1210×660×660mm (47.63" x 25.98" x 25.98"|
|Work Surface Height||720mm (28.34")|
|Max Opening||450mm (18’’)|
|Tested Opening||Safety height ≤200mm (8’’)|
|Front Window||Motorized.Two-layer laminated toughened galss ≥5mm. Anti UV|
|HEPA filter||Two, 99.999% efficiency at 0.3um, filter life indicator|
|Noise||NSF 49≤61 dB/EN 12469≤58 dB|
|Waterproof electrical outlet||2, Total consumption:≤500W|
|Tap||Water tap*1, Gas tap *1|
|Filter guard Type||Aluminium alloy frame|
|Ground Resistance||≤ 0.10Ω|
AC220/110V±10%, 50/60Hz ±1Hz, Full load Amps: 9A,
|Alarm||Abnormal airflow velocity; Filter change; Front Window over height|
One ECM motor, 110V& 220V acceptable, Speed adjustable,
high efficiency and low power consumption
Inflow: 465m3 /h (275cfm)
Downflow: 67% 956m3/h (571cfm)
Exhaust: 33% 465m3/h (275cfm)
working area: 304 stainless steel/ Frame and Decorative Plate: cold-rolled steel with anti-bacteria power coating
Germicidal UV lamp, Emission of 253.7 nm for most
Fluorescent lamp, UV lamp *2, Base stand, SS water & gas taps,
Drain valve, Waterproof sockets
Armrest, Airflow tester, Formalin fumigation sterilizer,
Infrared sterilizer, Adjustable base stand,
|Package size (W*D*H)||1493*955*1840mm (59" x 38" x 73")|
|Gross weight||300kg (662 lbs.)|
